DynaOne^® ISOTowing

Round braid made with 100% Dyneema^® SK78

Compact construction type for long service life

Extremely light and flexible, easy to splice

6 mm - 96 mm Ø

Technical data

Elongation at 10% of the breaking load: 0.60 %

Ø [mm]	Weight [kg/100 m]	Bl. real in splice [kN]	Bl. linear DIN according to EN ISO 2307 [kN]
6 mm Ø	2.20	36.00	40.00
8 mm Ø	3.80	64.00	71.11
10 mm Ø	5.70	96.00	106.67
12 mm Ø	8.60	143.00	158.89
14 mm Ø	11.50	190.00	211.11
16 mm Ø	15.00	250.00	277.78
18 mm Ø	18.40	290.00	322.22
20 mm Ø	22.90	350.00	388.89
22 mm Ø	26.70	410.00	455.56
24 mm Ø	31.70	490.00	544.44
26 mm Ø	37.20	570.00	633.33
28 mm Ø	43.00	650.00	722.22
30 mm Ø	48.70	710.00	788.89
32 mm Ø	55.60	790.00	877.78
34 mm Ø	62.10	870.00	966.67
36 mm Ø	68.70	950.00	1,055.56
38 mm Ø	76.40	1,050.00	1,166.67
40 mm Ø	85.90	1,140.00	1,266.67
44 mm Ø	103.10	1,360.00	1,511.11
46 mm Ø	112.70	1,430.00	1,588.89
48 mm Ø	119.30	1,580.00	1,755.56
52 mm Ø	140.60	1,860.00	2,066.67
56 mm Ø	162.30	2,150.00	2,388.89
60 mm Ø	185.90	2,460.00	2,733.33
64 mm Ø	210.00	2,780.00	3,088.89
68 mm Ø	238.70	3,160.00	3,511.11
72 mm Ø	268.50	3,560.00	3,955.56
76 mm Ø	300.70	3,990.00	4,433.33
80 mm Ø	332.90	4,420.00	4,911.11
84 mm Ø	367.10	4,850.00	5,388.89
88 mm Ø	397.40	5,170.00	5,744.44
96 mm Ø	472.50	6,020.00	6,688.89

Product details

Diameter

Color
